1. Specications Check
28
SCON-CB/CGB/LC/LCG
Item
Less than 400W 400 to 750W 3000W or more
PIO MAX. 10m
RS485 Total cable length 100m or less.
Cable Length
Field Network Refer to each Field Network specification
Operation Mode
Positioner Mode/Pulse Train Control Mode
(selected by Pulse Train Mode Changeover Switch ON Front Panel)
Positioner Mode
Number of Positions in Positioner
Mode
Standard 64 points, MAX. 512 points (PIO Type), 768 points (only for Field Network Type)
(Note) Number of positions differs depending on the selection in PIO pattern and field
network operation mode.
Input Pulse
Frequency
Differential System (Line Driver System): MAX. 2.5Mpps
Open Collector Type: MAX. 200Kpps (under condition AK-04 is used)
Pulse Train
Interface
(Dedicated
for CB/CGB)
Command Pulse
Multiplying Factor
(Electrical Gear: A/B)
Setting Range of A and B (set to parameter): 1 to 99999999 (4096 for V0005 and
earlier)
Feedback Pulse Frequency
(except for CB/CGB field network
type)
Differential System (Line Driver System) : MAX. 2.5Mpps
Open Collector Type :
MAX. 500Kpps (under condition JM-08 is used)
LED Display
(mounted on Front Panel)
PWR (green) : Normal Controller Start,
SV (green)
: Servo ON,
ALM (orange)
: Alarm Generated,
EMG (red) : Emergency Stop
Electromagnetic Brake Compulsory
Release
Switch (mounted on Front Panel)
Switching NOM (standard) /BK RLS (compulsory release)
Insulation Resistance
(Between Secondary-FG)
500V DC 10MΩ or more
Insulation Strength
(Between Primary-FG)
1500V AC for 1 min.
(Note) Withstand voltage of pressing operation using force sensor loadcell is 50V DC
Surrounding air temperature 0 to 40°C
Surrounding humidity 85%RH or less (should be no condensation or freeze)
Surrounding environment [Refer to 1.6 Installation and Storage Environment]
Surrounding storage
temperature
-20 to 70°C (should be no condensation or freeze)
Surrounding storage humidity 85%RH or less (should be no condensation or freeze)
Vibration Resistance
Frequency: 10 to 57Hz / Amplitude: 0.035mm (Continuous), 0.075 (Intermittently)
Frequency: 57 to 150Hz / Acceleration: 4.9m/s
2
(Continuous), 9.8m/s
2
(Continuous)
XYZ Each direction Sweep Time: 10min. Number of Sweep Times: 10 times
Impact Resistance
Operation: Half Sine Wave
Amplitude / Duration: 50m/s2 (5g) / 30ms
Altitude 1000m above sea level or less
Overvoltage Category Ⅱ
Environment
Pollution Degree 2
Mass Approx. 900g Approx. 1200g Approx. 2800g
Method Cooling Natural Air-Cooling Forced Air Cooling Forced Air Cooling
External Dimensions 58W × 194H × 121D [mm] 72W × 194H × 121D [mm] 92.7W × 300H × 187.7D [mm]
Note 1 In-rush current will flow for approximately 20ms after the power is turned ON (at 40°C).
Note that the value of in-rush current differs depending on the impedance and the internal element
temperature (thermistor type in-rush current control circuit) of the power supply line.
Note 2 Leak current varies depending on the capacity of connected motor, cable length and the surrounding
environment. Measure the leak current at the point where a ground fault circuit interrupter is to be
installed when leakage protection is conducted.
A ground fault circuit interrupter needs to be selected carefully considering the purposes of
prevention of fire and protection of human.
Use the harmonic type (for inverter) for the ground fault circuit interrupter.
Note 3 It is not necessary to supply power to PIO, SIO Converter without using PIO. In this case, set the
parameter No.74 “PIO Power Supply Monitor” to “1” (Invalid). It will generate the error code No. 0CF
“I/O 24V Power Supply Error” if the setting is not done.
