Chapter 13. Stacking

This chapter describe how to implement the stacking feature in the RackSwitch

G8000. The following concepts are covered:

•

“Stacking Overview” on page 148

•

“Stack Membership” on page 149

•

“Configuring a Stack” on page 153

•

“Managing a Stack” on page 157

•

“Upgrading Software in an Existing Stack” on page 159

•

“Replacing or Removing Stacked Switches” on page 161

•

“ISCLI Stacking Commands” on page 164

Default Chapter5
