214 RackSwitch G8000: Application Guide
RIP Configuration Example
The following is an example of RIP configuration.
Note: An interface RIP disabled uses all the default values of the RIP, no matter
how the RIP parameters are configured for that interface. RIP sends out RIP
regular updates to include an UP interface, but not a DOWN interface.
1. Add VLANs for routing interfaces.
2. Add IP interfaces with IPv4 addresses to VLANs.
3. Turn on RIP globally and enable RIP for each interface.
Use the following command to check the current valid routes in the routing table of
the switch:
For those RIP routes learned within the garbage collection period, that are routes
phasing out of the routing table with metric 16, use the following command:
Locally configured static routes do not appear in the RIP Routes table.
>> # vlan 2
>> (config-vlan)# enable
>> (config-vlan)# member 2
Port 2 is an UNTAGGED port and its current PVID is 1.
Confirm changing PVID from 1 to 2 [y/n]: y
>> (config-vlan)# exit
>> # vlan 3
>> (config-vlan)# enable
>> (config-vlan)# member 3
Port 3 is an UNTAGGED port and its current PVID is 1.
Confirm changing PVID from 1 to 3 [y/n]: y
>> (config-vlan)# exit
>> # interface ip 2
>> (config-ip-if)# enable
>> (config-ip-if)# address 102.1.1.1
>> (config-ip-if)# vlan 2
>> (config-ip-if)# exit
>> # interface ip 3
>> (config-ip-if)# enable
>> (config-ip-if)# address 103.1.1.1
>> (config-ip-if)# vlan 3
>> # router rip
>> (config-router-rip)# enable
>> (config-router-rip)# exit
>> # interface ip 2
>> (config-ip-if)# ip rip enable
>> (config-ip-if)# exit
>> # interface ip 3
>> (config-ip-if)# ip rip enable
>> (config-ip-if)# exit
>> # show ip route
>> # show ip rip
