Ice vulcan User Manual

B-3
Rev AA
ICE Vulcan Service Manual
Menu
Options
Value
Min
Max
Unit
Comments
Setting
Inputs
Encoder
EncoderMode
0:
Quadtrature
1
Select the
required Encoder
Mode
1: Single
Phase
EncoderNum-
berOfLines
3600
200
5000
No. of Lines
Encoder-
WheelDiame-
terHMM
10610
2500
25000
Hundredt
hs of mm
Enter the encoder
whell diameter in
hundredths of a mm
FixedProd-
uctSpeed
225
13
5000
units
If there is no
encoder, enter
fixed product (or
line) speed in
mm/sec or ft/ sec
FixedSpeed-
Products
0:
External
Encoder
1
Select Fixed
Speed Printing if no
encoder avaiable
1: Fixed
Speed
Printing
GapSensor
GapSensor-
ToBeakDis- tance
400
100
5000
distance in mm
GapSensor-
Type
0: Array
2
1: Auxiliary
2: Point
Ignored-
PrintsBehav-
iour
0: Ignore
2
Select the
required printer
behaviour when
prints are missed
1: Raise
Warn- ing
2: Raise
Fault
IgnoredPri
nt-
sThreshold
3
1
20
The number of
ignored prints
required before
action above
warning or fault
raised
LabelRepeat-
Count
2
1
100
