Ice vulcan User Manual

Labeller 3-16
ICE Vulcan Service Manual
Label Web
The labels are routed from the label supply mandrel, through the printhead assembly to the
label waste mandrel. This forms the label web.
Label Supply Mandrel
The label supply disc holds the label roll in place on the mandrel. The mandrel lock is used to
retain the roll in place. The mandrel lock indicates the locking and unlocking directions.
1
2
1. Mandrel Lock
2. Label Supply Disc
Figure 3-18: Label Supply Mandrel
Dancer Arm
The dancer arm is designed to absorb the change in tension of the label web, during its
movement through the LPA.
1
2
1. Dancer Arm
2. Dancer Arm Roller
Figure 3-19: Dancer Arm

Ice vulcan Specifications

General

Brand	Ice
Model	vulcan
Category	Label Maker
Language	English
