ICE Vulcan Service Manual
The warning label for moving parts is attached on the face of the baseplate
of the machine.
Figure 3-23: Moving Parts Warning Label
Warning
PERSONAL INJURY. Do not, under any circumstances, remove or
obstruct any warning, caution,
or instruction labels present on the
equipment. If any part of these labels become damaged,
worn or
removed they must be immediately replaced.
Sensors
The LPA is equipped with the following sensors to ensure correct
operation
of the system without manual intervention.
Label Gap Sensor
The label gap sensor detects the gap between each label. The LED (item 2,
Figure 3-24) displays the status of the sensor. Refer to “LED Indicator
Description” on page 6-17.
1
2
1.
Label Gap Sensor
2.
LED
Figure 3-24: Label Gap Sensor
