ICE Vulcan Service Manual
System Overview
Figure 3-1 shows the system overview of the Label Printer Applicator on a
production line.
1
2 3
12
4
11
5
10
9
6
7
8
1.
Ribbon Supply Mandrel
2.
Ribbon Waste Mandrel
3.
Peel Tip
4.
Label Supply Mandrel
5.
Conveyor
6.
Dancer Arm
7.
Vertical Stand with Conveyor (U Base)
8.
Caster
9.
CLARiTY Display
10.
E-Stop Button (LPA)
11.
E-stop Button (Conveyor)
12.
Label Waste Mandrel
13.
Printhead*
*
Components are not shown in the figure
Figure 3-1: System Overview
The main parts of the LPA are:
•
CLARiTY Display
•
Labeller
•
Printhead
For more information on other integral parts of the LPA, refer to “Main
Parts” chapter of
Operator Manual.
