Ice vulcan User Manual

Installing the Label Applicator 4-11
ICE Vulcan Service Manual
Mounting the LPA
Warning
PERSONAL INJURY. Follow manual handling guidelines when moving equipment and
loading labels.
5 Mount the two stand bars (item 4, Figure 4-5) to the LPA base (item 1).
There are three locations (item 2) on the LPA base to mount stand bars, choose the most
appropriate locations for horizontal mounting.
4
1
2
3
1. LPA Base
2. Location to Mount Stand Bars (X3)
3. M8 Screws (X2)
4. Stand Bars (X2)
Figure 4-5:LPA Base
