ICE Vulcan Service Manual
Caution
EQUIPMENT DAMAGE. The interconnecting cable must be
connected in the correct
orientation to avoid damage to the LPA
main board.
Labeller
The labeller consists of the following main parts:
Main Controller Board for the LPA
The main controller board is located behind the labeller unit. The
connector panel is directly
mounted to the main controller board.
Figure 3-3: Main Controller Board
Caution
EQUIPMENT DAMAGE. Care must be taken during servicing and
handling to ensure that the
connectors are not subjected to
mechanical stress. This may damage the main controller
board.
