Getting started with the CLARiTY 5-2
ICE Vulcan Service Manual
Figure 5-1 shows the home screen of the CLARiTY operator system.
Using the Home Page
11
1
11
2
3
4
10
5
9
8
6
7
1. Status Bar
2. Tools Button
3. Current Job Details Bar
4. Consumables
5. Ribbon
6. Labels
7. Print Position
8. Performance Information
9. Print Button
10. System Control Buttons
11. Home Button
12. Job Select Button
Figure 5-1: CLARiTY Home Page
Warning
PERSONAL INJURY. The LPA starts printing if you touch the status bar when the LPA is in OFFLINE
mode. Make sure that you do not touch the status bar if the LPA is not required to run.
