ICE Vulcan Service Manual
Gap Sensor and Print Roller Sensor PCB
The gap sensor and print roller sensor PCB is located near the peel tip assembly.
Gap Sensor and Print
Roller PCB
Figure 3-4: Gap Sensor and Print Roller PCB
Ribbon and Printhead Sensor PCB
The ribbon and printhead sensor PCB is located near printhead assembly.
2
1
1. Ribbon and Printhead Sensor PCB
2. Motor Drive Cover Plate Removed
Figure 3-5: Ribbon and Printhead Sensor PCB
