Installing the Label Applicator 4-10
ICE Vulcan Service Manual
4
Adjust the mounting fixture (item 1, Figure 4-1 on page 4-6) to be
centred over the
centre of the H base.
1
2
3
1.
H Base
2.
LPA
3.
Indicates Containment Area
Figure 4-4:LPA Contained Within H Base Footprint
Warning
PERSONAL INJURY. Ensure that the stand has been assembled
correctly and is secure (i.e.
casters locked) before mounting the LPA
to the stand.
Warning
PERSONAL INJURY. Follow the instructions on constructing the
stands and mounting the LPA.
