Installing the Label Applicator 4-9

ICE Vulcan Service Manual

Warning

PERSONAL INJURY. The Steps from 3 to 9 require two persons to

execute the actions.

Place the stand in position on the base (see Figure 4-3) and secure it using four M6 bolts,

washers and nuts (item 6, Figure 4-1 on page 4-6).

Figure 4-3:Horizontal Stand Location on H Base

Warning

There is only one location for the stand as shown in Figure 4-3. The

LPA must be contained

within the H base footprint as shown in

Figure 4-4 on page 4-8.

Note: Refer to the Stand Instructions for more information.
