Installing the Label Applicator 4-12
ICE Vulcan Service Manual
13 Using a level, check that both the conveyor belt and the
label applicator are close to “perfect horizontal alignment’ as
possible. Make adjustments if necessary.
LPA
Conveyor
Figure 4-8: Level Check
14 Visually check to ensure that the plane of the peel tip runs
perfectly parallel to the side of the box.
Peel Tip
Figure 4-9: Peel Tip Alignment
15 Use the leveling feet to make any fine adjustments to the
angle between the peel tip and the side of the box.
Otherwise, use the leveling feet to secure the LPA and stand in
