How to Configure the LPA 5-18
ICE Vulcan Service Manual
This feature is useful for setting the IP address of the LPA, or other initial
settings, if user don’t
have the capability to connect serially (RS-232).
Creating the Archive
Do the following tasks to create the archive:
1
Insert a USB memory stick into the LPA’s USB port.
2
Navigate to Tools > Setup > Control > CLARiTY Parameter Archives.
3
Select the Create Archive button at the bottom of the screen.
4
Name the Archive file (or keep the default name) and press OK.
5
Once the screen indicates the Archive was created successfully, press
OK.
6
Remove the USB memory stick from the LPA
Editing the Archive in CLARiTY Configuration Manager
Do the following tasks to edit the archive in CLARiTY Configuration
Manager:
1
Insert the USB memory stick into a USB port of the computer running
CLARiTY
Configuration Manager.
2
Locate the “Archives” folder for the USB memory stick on the left side
of the CLARiTY
Configuration Manager window (i.e. “D:\Archives”)
and press the “+” next to the folder.
Figure 5-11: CLARiTY Config
3
Locate the archive file you wish to edit from the list and right-click on
the file name.
To Next Page
