Icom IC-7300 HF Plus User Manual

iv
Functions and features of Adobe
®
Acrobat
®
Reader
®
The following functions and features can be used with Adobe
®
Acrobat
®
Reader
®
.
• Keyword search
Click “Find (Ctrl+F)”
or “Advanced Search
(Shift+Ctrl+F)” in the Edit menu
to open the search screen.
This is convenient when
searching for a particular word or
phrase in this manual.
* The menu screen may differ,
depending on the Adobe
®
Acrobat
®
Reader
®
version.
• Find screen
• Advanced search screen
Click to open the nd or search
screen or advanced search screen.
• Printing out the desired pages.
Click “Print” in File menu, and then select the paper
size and page numbers you want to print.
* The printing setup may differ, depending on the
printer. Refer to your printer’s instruction manual
for details.
* Select “A4” size to print out the page in the
equalized size.
• Read Out Loud feature.
The Read Out Loud feature reads aloud the text in
this Instruction Manual.
Refer to the Adobe
®
Acrobat
®
Reader
®
Help for the
details.
( This feature may not be usable, depending on your
PC environment including the operating system.)
* The screen may differ, depending on the Adobe
®
Acrobat
®
Reader
®
version.
Previous view

Icom IC-7300 HF Plus Specifications

General

Type	HF/50 MHz Transceiver
Modes	SSB, CW, RTTY, AM, FM
Receiver Type	Direct Sampling
Antenna Connector	SO-239
Antenna Impedance	50 ohms
Power Supply	13.8V DC ±15%
Frequency Coverage	0.030-74.800 MHz
RF Output Power	100 W
Receiver Sensitivity	0.15 μV (typical)
Receiver Selectivity	SSB: 2.4 kHz, CW: 500 Hz
Image Rejection Ratio	70 dB
IF Rejection Ratio	70 dB (HF bands), 60 dB (50 MHz band)
Audio Output Power	2.5 W (at 10% distortion)
Display	4.3-inch color TFT touch screen
Dimensions	240 x 94 x 238 mm
Number of Channels	101 (99 regular, 2 scan edge)
Current Consumption	21A (maximum transmission)
