 3x1, 4x1, 4x2 and 4x3 Formats

For FORMAT, see Table 1: FORMAT Description

03 DEC 2000 16:48

LCx FORMAT ACCT

PLAIN LIB

EC UVE

For EC for 4x2 see 4.4.3 Plain Library Overview

 Contact ID

03 DEC 2000 16:48

LCx CONT ID ACCT

CID Plain Library

Event QXYZGGCCC UVE

To alter the format see 4.3.7 Format Options M107

 SIA Format

03 DEC 2000 16:48

LCx SIA ACCT

SIA Plain Library

Event TTDDD –-> UVE

Where:

• LCx The Line Card [1...4] number that received the event

• FORMAT The format used to receive the event see Table 1 Format Description

• ACCT The account code of the source of the event.

• PLAIN LIB The Plain Library text related to the received event code.

• EC This is the 1, 2 or 3 digit received event code

• QXYZ The “Contact ID” event code where Q = Qualifier, XZY= Event code

• TTDDD The SIA event code where TT = AA to ZZ event code and DDD = variables

related to the event.

• GG Group Number, on Ver 3.06 and >.

• CCC A three digit zone or user number part of the “Contact ID” event code.

• UVE The “Un-viewed” event number is the number of events that have been

added to the log while viewing the currently displayed event or the number

of events scrolled backwards (down) relative to the latest event entered into

the log.
