IEI Technology ROCKY-4786EVG User Manual

1-10
3
ROCKY-4786EVG CPU Card
103

Disabled
The CPU card will not use the primary IDE channel

Enabled
(D
EFAULT) The CPU card will use the primary IDE channel
 IDE PIO [Auto]
The Programmed Input/Output (PIO) mode for the following HDDs can all be selected.
 IDE Primary Master PIO
 IDE Primary Slave PIO
 IDE Secondary Master PIO
 IDE Secondary Slave PIO

Auto
(D
EFAULT) Allows the computer to select the correct mode

0
PIO mode 0 selected with a maximum transfer rate of 3.3MBps
1
PIO mode 1 selected with a maximum transfer rate of 5.2MBps
2
PIO mode 2 selected with a maximum transfer rate of 8.3MBps
3
PIO mode 3 selected with a maximum transfer rate of 11.1MBps
4
PIO mode 4 selected with a maximum transfer rate of 16.6MBps
 IDE UDMA [Auto]
The Ultra DMA (UDMA) mode for the following HDDs can all be selected.
 IDE Primary Master UDMA
 IDE Primary Slave UDMA
 IDE Secondary Master UDMA
 IDE Secondary Slave UDMA

Auto
(D
EFAULT) Allows the computer to select the correct UDMA

Disabled
Disables the UDMA for the HDD device
 On-Chip Secondary PCI IDE [Auto]
