ROCKY-4786EVG CPU Card
35
3.1.2 Peripheral Interface Connectors
Table 3-1 shows a list of the peripheral interface connectors on the ROCKY-4786EVG
CPU board. Detailed descriptions of these connectors can be found in Section 3.2.
Label Connector Type
IDE1 Primary & Secondary IDE connectors 40-pin header
IDE2 Primary & Secondary IDE connectors 40-pin header
FDD1 Floppy drive 34-pin header
LPT1 Parallel port connector 26-pin header
COM1 Serial port connectors 5-pin header
COM2 Serial port connectors 5-pin header
CF1
Compact Flash Storage Card Type II
connector
50-pin header
IR1 IrDA infrared interface port 5-pin header
USB1 USB dual port connector 8-pin header
USB2 USB dual port connector 8-pin header
USB3 USB dual port connector 8-pin header
USB4 USB dual port connector 8-pin header
CN5 External Keyboard Connector 5-pin header
FAN1 System Fan connector 3-pin header
FAN2 CPU Fan connector 3-pin header
SATA1 Serial ATA connectors SATA disk drive port
SATA2 Serial ATA connectors SATA disk drive port
CN1 Front Panel Connector 4-pin header
CN2 ATX +12V Power connector 4-pin header
CN3 LAN State LED connectors 4-pin header
