IEI Technology ROCKY-4786EVG User Manual

1-36
36
IEI
®
Technology, Corp.
CN4 LAN State LED connectors 4-pin header
CD-IN Audio CD in connector 4-pin header
LINE-IN Audio LINE in connector 4-pin header
MIC-IN Audio MIC in connector 4-pin header
PW-SW1 ATX Power Button connector 2-pin header
ATXCTL1 Backplane to Main board ATX power
control Connector
3-pin header
Table 3-1: Peripheral Interface Connectors
3.1.3 Rear Panel Connectors
Table 3-2 lists the rear panel connectors on the ROCKY-4786EVG CPU card. Detailed
descriptions of these connectors can be found in Section 4.5.
Label Connector Type
KB/MS1 Keyboard or Mouse connector PS/2
LAN1 Ethernet connector RJ-45
LAN2 Ethernet connector RJ-45
SPK_OUT AUDIO connector LINE OUT
VGA1 VGA connector 15-pin VGA connector
Table 3-2: Peripheral Interface Connectors
3.1.4 Onboard Jumpers
Table 3-3 lists the onboard jumpers. Detailed descriptions of these jumpers can be found in
Section 0.
Label Connector Type
JP1 Compact Flash Master/Slave Setting 2-pin header
