IEI Technology ROCKY-4786EVG User Manual

1-72
72
IEI
®
Technology, Corp.
 DIMMs must use the same density memory chips
 Both DIMMs must use the same DRAM bus width
 Both DIMMs must be either single-sided or dual-sided.
4.3.3.2 DIMM Module Installation
The ROCKY-4786EVG CPU Board has two DDR SDRAM DIMM sockets. To install the
DIMM modules, follow the instructions below.
Step 4: Pull the two white handles on either side of the DIMM socket down.
Step 5: Align the DIMM module with the DIMM socket making sure the matching pins
are correctly aligned.
Step 6: Insert the DIMM module slowly. Once you are sure it is correctly inserted, push
down firmly. The white handles on either side of the socket will move back up
and lock the module into the socket. Step 0:
4.3.4 Peripheral Device Connection
Cables provided by IEI that connect peripheral devices to the CPU Card are listed in Table
4-1. Cables not included in the kit must be separately purchased.
Quantity Type
1 ATA 66/100 flat cable
2 SATA cables
1 SATA power cable
1 Keyboard/ PS2 mouse Y cable
1 ATX 12V cable
1 Mini Jumper
1 RS-232 cable
1 USB cable
Table 4-1: IEI Provided Cables
