ROCKY-4786EVG CPU Card

NOTE:

1. SATA is supported by:

• Windows 2000 SP4

• Windows XP SP1

• Windows 2003, or later versions.

2. Older OSes, such as Windows 98SE or ME, do not support the SATA interface.

3.2.11 Keyboard Connector

CN Label: CN5

CN Type: 1x5 pin header

CN Location: See Figure 3-12

CN Pinouts: See Table 3-14

For alternative application, a keyboard pin header connector is also available on board.

PIN NO. DESCRIPTION

1 KEYBOARD CLOCK

2 KEYBOARD DATA

3 N/C

4 GND

5 +5V

Table 3-14: CN5 Connector Pinouts
