ROCKY-4786EVG CPU Card

3.2.5 Internal USB Connectors

CN Label: USB1, USB2, USB3, USB4

CN Type: 2x4 pin header

CN Location: See Figure-3-6

CN Pinouts: See Table-3-8

Four 2x4 pin connectors provide connectivity to eight USB 2.0 ports. The USB ports are

used for I/O bus expansion.

PIN DESCRIPTION PIN DESCRIPTION

1 VCC 2 GND

3 DATA0- 4 DATA1-

5 DATA0+ 6 DATA1+

7 GND 8 VCC

Table-3-8: USB Port Connector Pinouts
