1-31
ROCKY-4786EVG CPU Card
31
Voltage Current
+5V 6.98
+12V 7.52
Table 2-2: Power Consumption
2.19 Packaged Contents and Optional Accessory Items
2.19.1 Package Contents
When you unpack the ROCKY-4786EVG CPU board, you should find the following
components.
1 x ROCKY-4786EVG CPU card.
1 x SATA power cable (P/N: 32100-088600-RS).
2 x SATA cables (P/N: 32000-062800-RS).
1 x Mini jumper pack (P/C: 33100-000079-RS).
1 x RS-232 cable (2 COM ports; P/N: 19800-000051-RS).
1 x power cord (P/N: 32100-087100-RS).
1 x USB adapter cable (P/N: CB-USB02-RS).
1 x IDE HDD cable (P/N: 32200-000052-RS).
1 x PS/2 keyboard/mouse Y-cable (P/N: 32000-000138-RS).
1 x Driver and Utility CD.
1 x QIG (Quick Installation Guide).
2.19.2 Optional Accessory Items
The items shown in the list below are optional accessory items are purchased separately.
Audio cable (MIC In / LINE In) (P/N: 19800-000002-RS)
FDD cable (P/N: 32200-000017-RS)
LPT cable (P/N: 19800-000049-RS)
