1-17
ROCKY-4786EVG CPU Card
17
devices
Floppy Disk Drive (FDD) Supports FDD
USB Interfaces Eight USB 2.0 connectors supported
Serial Ports Two COM ports
Real Time Clock 256-byte battery backed CMOS RAM
Hardware Monitoring Cooling fans, temperature and system voltages
Power Management Supports Advanced Configuration and Power Interface
(ACPI) Specifications Revision 2.0
Infrared Support One Infrared Data Association (IrDA) interface
Ethernet Gigabit Ethernet (GbE) or 10/100BaseT
BIOS AMI flash BIOS
Physical Dimensions 38.0cm x 12.5cm (width x length)
Operating Temperature Minimum: 0ºC (32°F)
Maximum: 60°C (140°F)
Audio Interfaces One Audio Codec ’97 (AC’97) version 2.2 connector
Table-1-1: Technical Specifications
