3.2.8 System Front Panel Connector
CN Label: CN1
CN Type: 2x7 pin header
CN Location: See Figure 3-9
CN Pinouts: See Table 3-10
The system panel connector connects to:
the system chassis front panel LEDs
the chassis speaker
the power switch
the reset button.
PIN DESCRIPTION PIN DESCRIPTION
1 +5V 2 Speaker+
3 N/C 4 N/C
Power LED
5 GND 6 N/C
7 N/C 8 Speaker-
Speaker
9 N/C
10 Reset PIN1
11 GND 12 Reset PIN2
Reset Button
HDD LED 13 HDD LED+ 14 HDD LED- HDD LED
Table 3-11: System Panel Connector Pinouts
