4.2.2 Checklist
When you unpack the ROCKY-4786EVG, please make sure that your package contains
the following items.
1 x Rocky-4786-RS-R40 single board computer
1 x HDD cable P/N: 32200-000052-RS
2 x SATA cable P/N: 32000-062800-RS
1 x SATA power cable P/N: 32100-088600-RS
1 x Keyboard/ PS2 mouse Y cable P/N: 32000-000138-RS
1 x ATX-12V cable P/N: 32100-087100-RS
1 x RS-232 cable P/N: 19800-000051-RS
1 x USB cable P/N: CB-USB02-RS
1 x mini jumper pack
1 x Utility CD
1 x QIG (quick installation guide)
If one or more of these items are missing, please contact the reseller or vendor you
purchased the ROCKY-4786EVG CPU card from and do not proceed any further with the
installation.
4.3 ROCKY-4786EVG CPU Card Installation
WARNING!
1. Never run the CPU board without an appropriate heat sink and cooler
that can be ordered from IEI Technology or purchased separately.
2. Be sure to use the CPU 12V power connector (CN10007) for the CPU
power.
WARNING!
Please note that the installation instructions described in this manual should
be carefully followed in order to avoid damage to the CPU Card components
and injury to you.
