IEI Technology ROCKY-4786EVG User Manual

1-16
16
IEI
®
Technology, Corp.
The ROCKY-4786EVG CPU board has the following connectors on the board rear panel:
 1 x PS/2 connector
 1 x VGA connector
 1 x LINE_OUT connector
 1 x RJ-45 Ethernet connector
 2 x USB ports
The location of these connectors on the CPU Card can be seen in Error! Reference source
not found.. These connectors are fully described in Chapter 2.
NOTE:
There are no configuration jumpers or connectors on the soldering side.
1.2.2 Technical Specifications:
ROCKY-4786EVG CPU board technical specifications are listed in Table-1-1. Detailed
descriptions of each specification can be found in Chapter 2.
SPECIFICATION
CPUs Supported
Intel
®
Pentium
®
4
Intel
®
Celeron
®
D
Chipsets
Northbridge: Intel
®
865GV
Southbridge: Intel
®
ICH5
I/O Controller ICH5
Graphics Support Intel® Extreme Graphic II integrated graphic engine
Memory Two DDR memory modules (Max. 2GB)
PCI Bus Interface 33MHz, Revision 2.3
Serial ATA (SATA) Two SATA channels with 1.5GB/s transfer rates
HDD Interface Two IDE channels supports four Ultra ATA 100/66/33
