IEI Technology ROCKY-4786EVG User Manual

1-43
ROCKY-4786EVG CPU Card
43
3.2.4 Parallel Port
CN Label: LPT1
CN Type: 2x13 pin header
CN Location: See Figure-3-5
CN Pinouts: See Table-3-7
The parallel port is connected to a printer or other parallel device with a 26-pin flat-cable
connector.
PIN DESCRIPTION PIN DESCRIPTION
1 STROBE# 14 AUTO FORM FEED #
2 DATA0 15 ERROR#
3 DATA1 16 INITIALIZE#
4 DATA2 17 PRINTER SELECT LN#
5 DATA3 18 GND
6 DATA4 19 GND
7 DATA5 20 GND
8 DATA6 21 GND
9 DATA7 22 GND
10 ACKNOWLEDGE# 23 GND
11 BUSY 24 GND
12 PAPER EMPTY 25 GND
13 PRINTER SELECT
Table-3-7: LPT Connector Pinouts
