1-14
3
ROCKY-4786EVG CPU Card
143
6.5 USB2.0 Driver Installation
To install the USB2.0 driver, please follow the steps below:
Step 1: To the right of the USB2.0 menu item, you may select either \USB20\Intel\ to
browse the driver directory, or click on any of the Win9X\ME
, Win2000, or
WINXP buttons to install the appropriate USB 2.0 driver. If you click on either the
Win9X\ME
or Win2000 button, a new window will open to the CD folder where a
readme.txt file can be read for information on how to install the USB 2.0 driver
for the corresponding OS.
Step 2: Once you click on the WINXP button, the install shield wizard for the USB 2.0
driver starts. See Figure 6-15.
Figure 6-15: USB 2.0 Driver Install Shield Wizard Starting
Step 3: After install shield is prepared, the welcome screen shown in Figure 6-16
appears. To continue the installation process, click the “N
EXT” button. A License
Agreement screen shown in Figure 6-17 will appear. Read the license
agreement.
To Next Page
