3.4 Onboard Jumpers
NOTE:
A jumper is a metal bridge that is used to
close an electrical circuit. It consists of
two metal pins and a small metal clip
(often protected by a plastic cover) that
slides over the pins to connect them. To
CLOSE/SHORT a jumper means
connecting the pins of the jumper with
the plastic clip and to OPEN a jumper
means removing the plastic clip from a
jumper.
The ROCKY-4786EVG CPU Board has two onboard jumpers. See Table 3-3.
Figure 3-18 Jumper
