IEI
®
Technology, Corp.
4.4 Chassis Installation
After the CPU, the cooling kit, and the DIMM modules have been installed and after the
internal peripheral connectors have been connected to the peripheral devices and the
jumpers have been configure, the CPU Card can be mounted into chassis.
To mount the CPU Card into a chassis please refer to the chassis user guide that came
with the product.
4.5 Rear Panel Connectors
4.5.1 LCD Panel Connection
The conventional CRT monitor connector, VGA1, is a 15-pin, female D-SUB connector. It
can be connected to an external monitor. Pin assignments are shown in Figure 3-17.
4.5.2 Line Out Connection
Connect an audio device to the line out connector on the rear panel.
4.5.3 Ethernet Connection
The rear panel RJ-45 connectors can be connected to an external LAN and communicate
with data transfer rates up to 1Gb/s.
