selected, COM2 will be disabled.

ASKIR
ASKIR is set as the IR serial mode. If this option is
selected, COM2 will be disabled.

Normal
(D
EFAULT) COM2 is enabled and the IR device disabled
 x RxD, TxD Active [Hi,Lo]
The RxD, TxD Active BIOS option allows you to set the infra-red reception (RxD) and
transmission (TxD) polarity. (This option can only be selected if the UART is set in IrDA
mode or ASKIR mode.) The following configuration options are available,
 Hi, Hi
 Hi, Lo (DEFAULT)
 Lo, Hi
 Lo, Lo
 x IR Transmission Delay [Enabled]

Disabled

Enabled
(D
EFAULT)
 UR2 Duplex Mode [Half]

Full

Half
(D
EFAULT)
 Use IR Pins [IR-Rx2Tx2]

RxD2, TxD2

IR-Rx2Tx2
(D
EFAULT)
 Onboard Parallel Port [378/IRQ7]
The Onboard Parallel Port option allows you to select the I/O address and IRQ for the
onboard parallel port. The following configuration options are available,
