ROCKY-4786EVG CPU Card

CN Pinouts: See Table 3-10

Connects a power source from a backplane with an ATX Connector.

PIN NO. DESCRIPTION

1 5VSB

2 ATX-ON

3 GND

Table 3-10: CN7 Connector Pin Outs

Figure 3-8: ATXCTL Connector Locations
