WAFER-LX Motherboard
Page 98
Î VSYNC Polarity Active [Low]
The VGSYNC Polarity Active option can only be configured if the Flat Panel Type option
is not set to Auto. Use the VGSYNC Polarity Active option to set the polarity of the
VSYNC signal to the panel. The VGSYNC Polarity Active options are:
High
Low (Default)
Î SHFCLK Active Period [Free Running]
Use the SHFCLK Active Period option to set the SHFCLK. The SHFCLK Active Period
options are:
Active Only
Free running (Default)
Î LP Active Period [Free Running]
Use the LP Active Period option to set the LDE/MOD signal to the panel. The LP Active
Period options are:
Active Only
Free running (Default)
