WAFER-LX Motherboard
Page 30
Connector Type Label
IDE Interface connector 44-pin header CN30
Inverter power connector 5-pin header CN3
Keyboard/Mouse connector 6-pin header CN17
LED connector 6-pin header CN5
Parallel port connector 26-pin header CN15
PC/104 power input connector 3-pin header CN11
PC/104 slot 104-pin slot CN10
Reset button connector 2-pin header CN12
RS-232/422/485 serial port connector 14-pin header CN16
SATA drive connector (150 MB/s) 7-pin SATA connector CN23
SATA drive connector (150 MB/s) 7-pin SATA connector CN25
TFTLCD LVDS connector 20-pin header CN29
TFT LCD TTL connector 40-pin header CN28
USB connector (USB 1.1 and USB 2.0) 8-pin header CN24
Table 4-1: Peripheral Interface Connectors
4.1.3 External Interface Panel Connectors
Table 4-2 lists the rear panel connectors on the WAFER-LX. Detailed descriptions of
these connectors can be found in Section
4.3 on page 57.
Connector Type Label
Ethernet connector RJ-45 CN20
Ethernet connector RJ-45 CN21
RS-232 serial port connector 9-pin male CN22
USB port USB port CN19
VGA port connector 15-pin female CN26
Table 4-2: Rear Panel Connectors
