WAFER-LX Motherboard
Page 68
Quantity Type
2 SATA cables
1 SATA power cable
1 RS-232 cable
1 USB cable
Table 5-1: IEI Provided Cables
5.4.2.1 IDE Disk Drive Connector (IDE1)
The cable used to connect the motherboard to the IDE HDD is a standard 44-pin ATA
66/100 flat cable. To connect an IDE HDD to the motherboard, follow the instructions
below.
Step 1: Find the ATA 66/100 flat cable in the kit that came with the motherboard.
Step 2: Connect one end of the cable to the PIDE1 connector on the motherboard. A
keyed pin on the IDE connectors prevents it from being connected incorrectly.
Step 3: Locate the red wire on the other side of the cable that corresponds to the pin 1
connector.
Step 4: Connect the other side of the cable to the HDD making sure that the pin 1 cable
corresponds to pin 1 on the connector.Step 0:
NOTE:
When two EIDE disk drives are connected together, back-end jumpers
on the drives must be used to configure one drive as a master and the
other as a slave.
