WAFER-LX Motherboard
Page 65
Do not place a PCB on top of an anti-static bag. Only the inside of the bag is safe from
static discharge.
5.3.2 Checklist
When unpacking the WAFER-LX, please make sure that the package contains the
following items.
1x WAFER-LX800 single board computer
1 x Mini jumper pack
1 x IDE flat cable 44P/44P
2 x SATA cables
1 x SATA power cable
1 x Audio cable
1 x KB/MS cable
1 x USB cable
1 x RS-232 cable
1 x Utility CD
1 x Quick Installation Guide
If one or more of these items are missing, please contact the reseller or vendor the
WAFER-LX was purchased from and do not proceed any further with the installation.
5.4 Installation Procedure
WARNING!
Never run the motherboard without an appropriate heatsink and cooler
that can be ordered from IEI Technology or purchased separately.
Be sure to use the CPU 12 V power connector (CN10007) for the CPU
power.
