WAFER-LX Motherboard
Page 5
Figure 1-2: WAFER-LX Solder Side Overview
The WAFER-LX has the following connectors on-board:
1 x AT power connector
1 x ATX power function connector
1 x Audio connector
1 x Battery connector
1 x Compact Flash (CF) connector (solder side)
1 x External LED connector
1 x Fan connector
1 x Floppy disk drive connector (slim type, optional)
1 x General purpose input/output (GPIO) connector
1 x IDE Interface connectors (44-pin)
1 x Inverter power connector
1 x Keyboard/mouse connector
1 x Parallel port connector
1 x PC/104 slot
1 x PC/104 power connector
