IEI Technology WAFER-LX-800-R12 User Manual

WAFER-LX Motherboard
Page 72
COM2 Setup Description
2-4 12 V
4-6 or 6-8 5 V
8-10 RI Default
Table 5-6: COM2 Pin 9 Setup
5.5.4 LCD Voltage
Jumper Label: JP4
Jumper Type:
3-pin header
Jumper Settings:
See
Table 5-7
Jumper Location:
See
Figure 5-2
This jumper settings sets the voltage of the power supplied to the LCD panel.
LCD Voltage Setup Description
1-2 3.3 V Default
2-3 5 V
Table 5-7: COM3 Setup Jumper Settings
5.5.5 CompactFlash® Master/Slave Setup
Jumper Label: JP5
Jumper Type:
3-pin header
Jumper Settings:
See
Table 5-8
Jumper Location:
See
Figure 5-2
This jumper sets the CompactFlash® as either the IDE master or slave.
CompactFlash® Setup Description
1-2 IDE Slave Default
