WAFER-LX Motherboard
Page 192
E.2 1
st
MB Memory Address Map
Memory address Description
00000-9FFFF System memory
A0000-BFFFF VGA buffer
F0000-FFFFF System BIOS
1000000-
Extend BIOS
Table E-2: 1
st
MB Memory Address Map
E.3 IRQ Mapping Table
IRQ0 System Timer IRQ8 RTC clock
IRQ1 Keyboard IRQ9 ACPI
IRQ2 Available IRQ10 LAN
IRQ3 COM2 IRQ11 LAN/USB2.0/SATA
IRQ4 COM1 IRQ12 PS/2 mouse
IRQ5 SMBus Controller IRQ13 FPU
IRQ6 FDC IRQ14 Primary IDE
IRQ7 Available IRQ15 Secondary IDE
Table E-3: IRQ Mapping Table
