WAFER-LX Motherboard
Page 16
Feature AMD Geode™ LX Processor
Color Pattern 8, 16, 32 bpp
Transparent Pattern Monochrome
Solid Fill Yes
Pattern Fill Yes
Transparent Source Monochrome
Color Key Source Transparency Y with mask
Variable Source Stride Yes
Variable Destination Stride Yes
Destination Write Bursting Yes
Selectable BLT Direction Vertical and Horizontal
Alpha BLT
Yes (constant α, α/pix, or sep. α channel)
VGA Support Decodes VGA Register
Pipeline Depth Unlimited
Accelerated Rotation BLT 8, 16, 32 bpp
Color Depth Conversion 5:6:5, 1:5:5:5, 4:4:4:4, 8:8:8:8
Table 2-1: Geode LX Graphics Features
2.7 Memory Support
The WAFER-LX has one 200-pin DDR SO-DIMM SDRAM socket that supports one
333 MHz or 400 MHz DDR SO-DIMM memory module with a maximum capacity of
1.0 GB.
2.8 PCI Bus Interface Support
The PCI bridge on the WAFER-LX has the following features:
33 MHz Revision 2.2 is implemented
Maximum throughput: 133 MB/s
PCI and GLIU interface control
Read and write FIFOs
PCI
