WAFER-LX Motherboard
Page 100
Master Drive PIO Mode
Slave Drive PIO Mode
Î
Auto DEFAULT
The computer selects the correct mode.
Î
Mode 0
PIO mode 0 selected with a maximum transfer rate of 3.3 MB/s.
Î
Mode 1
PIO mode 1 selected with a maximum transfer rate of 5.2 MB/s.
Î
Mode 2
PIO mode 2 selected with a maximum transfer rate of 8.3 MB/s.
Î
Mode 3
PIO mode 3 selected with a maximum transfer rate of 11.1 MB/s.
Î
Mode 4
PIO mode 4 selected with a maximum transfer rate of
16.6 MB/s.
Î
Mode 5
PIO mode 5 selected with a maximum transfer rate of
22.2 MB/s.
Î IDE UDMA [Auto]
Use the IDE UDMA option below to select the Ultra DMA (UDMA) mode for the following
HDDs:
IDE Primary Master UDMA
IDE Primary Slave UDMA
Î
Auto DEFAULT
The computer selects the correct UDMA.
Î
Disabled
The UDMA for the HDD device is disabled.
Î IT8888 ISA Decode IO
Use the IT8888 ISA Decode IO menu (
BIOS Menu 7) to set the IO memory range for the
onboard ISA. See Section
0.
Î IT8888 ISA Decode Memory
Use the IT8888 ISA Decode Memory (
BIOS Menu 8) to set the resources for the
onboard ISA bus. See Section
6.5.2.
