WAFER-LX Motherboard
Page 102
Disabled
3F8/IRQ4
2F8/IRQ3 (Default)
3E8/IRQ4
2E8/IRQ3
Auto
Î Onboard Serial Port 3 [Disabled]
Use the Onboard Serial Port 3 option to select the I/O address and IRQ for the onboard
serial port 2. The serial port can be disabled or the I/O address and the IRQ can be
automatically selected by the BIOS. The Onboard Serial Port 3 options are:
Disabled (Default)
3F8/IRQ4
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Auto
Î Onboard Parallel Port [378/IRQ7]
Use the Onboard Parallel Port option to specify a logical LPT port address and
corresponding interrupt for the physical parallel port. The Onboard Parallel Port options
are:
Disabled
378/IRQ7 (Default)
278/IRQ5
3BC/IRQ7
Î Parallel Port Mode [SPP]
Use the Parallel Port Mode option to select parallel port operation mode.
