DC Volts, V Ranges: 2 MΩ
AC Volts, mv Ranges:20 KΩ, in series with 1 µf
AC Volts, V Ranges: 2 MΩ
Permitted Source Impedance
mv Ranges: 20 kΩ
V Ranges: 5 kΩ
Temperature Drift of Zero Line
mv Ranges: approx. 0.5 µv/K
V Ranges: approx. 50 µv/K
Long Term Drift: 1 µv/month
Overload Protection:
mv Ranges: ±60V
V Ranges: ±60V
Chart Drive (Crystal Controlled Stepping Motor)
Chart Speeds 1, 2, 5, 10, 20, 50, 100 cm/min
1, 2, 5, 10, 20, 50, 100 cm/hr
1.2, 3, 6, 12, 30, 60 cm/min
1.2, 3, 6, 12, 30, 60, 120 cm/hr
(all speeds forward and reverse)
Input Voltage 100, 110, 220, 240 Va.c. ±10%
Ordering information for Strip Chart Recorder supplies
is given in Table 6-1
System Options
Strip Chart Recorder
6-5
