Paper Hold-down: Electrostatic
Max Writing Speed
X-Axis: 70 cm/sec
Y-Axis: 100 cm/sec
Cutoff Frequency @ -3dB
X-Axis: 1.4 Hz (280 mm)
Y-Axis: 3 Hz (200 mm)
Power Consumption
Operating: 25 VA
Standby: 10 VA
Input Voltage: 100, 110, 220, 240 Va.c. ±10%
Dimensions (WxHxD) 379.5x150x372 mm
Weight: 7 kg approx.
Ordering information for X-Y Recorder supplies is
given in Table 6-4
Part Number Description Quantity
3750-139 Sheet Paper, metric
units
100 sheets/pkg
3750-140 Sheet Paper, U.S.
Customary units
100 sheets/pkg
3750-144 Pens, blue 5 pens/pkg
3750-145 Pens, red 5 pens/pkg
3750-146 Pens, black 5 pens/pkg
Table 6-4. Recorder Supplies
X-Y Recorder M10-94400-1
6-14
