Instron 4400 Series - Example Pip Delay Values Vs Test Speeds

Test Speed (in/min) Delay (seconds)
above 20 0
20 0.100
1 2.000
0.1 20.00
below 0.0002 9999
Test Speed (mm/min) Delay (seconds)
above 1000 0
100 0.500
50 1.000
1 50.00
0.1 500.0
0.005 9999
Table 6-10. Example Pip Delay Values vs Test Speeds
System Options
Pip Control
6-43
