Specifications
AC/DC Strain Conditioner
Catalog Number 2210-865
Input Differential ±11V maximum
10 Kohm max impedance
Calibration ±7to±11 Volts, full scale
sum of signal and imbalance
must not exceed ±11 V input
maximum
Input Selection Automatic by jumper in adapter
(DC vs AC) cable
Installation
If the AC/DC Strain Conditioner Option has not already
been installed, you can do it yourself by following these
steps:
(a) Shut off all electrical power to the system.
(b) Disconnect all cables from the rear of the console.
Tag each cable if you are not sure where they will go
when you replace them.
(c) Remove the console from the load frame by discon-
necting the two halves of the mounting bracket.
(d) Lay the console face down on a flat, smooth surface.
Use a cloth or pad under the console if the work sur-
face is rough or dirty.
(e) Remove the six M4 socket head screws that attach
the rear cover to the console case, and retain these
screws. Lift off the rear cover and set it aside. It is
System Options
AC/DC Strain Conditioner
6-31
