When “HELP” is on the display, press [ENTER] to
change the display to “E”. This indicates that the Error
type command is in effect.
The “E” type commands are numbered 0 through 9, ex-
cept “4” and “7”, which are not used. You must enter
one of these numbers on the keypad, followed by [EN-
TER] to execute an “E” command. E0 lists error mes-
sages in all functional sections, E1 to E8 lists error
messages for sections 1 through 8 (except 4 and 7), re-
spectively, and E9 prints the list of error messages.
Table 8-1 lists the functional sections in the Series 4400
control console.
The following examples show the use of “E” commands
after entering the Diagnostics Monitor as described pre-
viously.
EXAMPLE NO. 1:
To display errors for each Section sequentially, 1
through 8:
Section No. Functional Name Basic or Option
1
2
3
4
5
6
7
8
IEEE-488 Interface
Central Processing Unit (CPU)
Crosshead Control
(Not Used)
Load Sensor Conditioner
Strain Sensor Conditioner
(Not Used)
Recorder Interface
Option
Basic
Basic
--
Basic
Option
—
Option
Table 8-1. Sections of the Control Console
Maintenance
Error Messages
8-5
