proper value for the line voltage in use (see the Recorder
manual).
If the Strip Chart Recorder is to be adapted for 200-240
Va.c. operation, you must alter the power cable by in-
stalling a male plug on the power cable that is specified
for that power source outlet. Observe the following CEE
wire color code for the cable:
Brown - high (live)
Light Blue - low (neutral)
Green & Yellow - earth/ground
Installation
To use the recorder with a Series 4400 system, place the
recorder on any horizontal, flat, relatively level work sur-
face near the load frame. The recorder is designed to op-
erate in a horizontal position, so do not prop it up
vertically or on a slant.
Determine the line voltage of the mains supply, and if
necessary, set the line voltage selector on the recorder as
described in the previous section.
If Line Voltage is:
Set a.c. input connector
to:
120 ±10 Vac
100 ±10 Vac
220 ±10 Vac
240 ±10 Vac
Table 6-2. Recorder Line Voltage Selection
System Options
Strip Chart Recorder
6-7
